HORIZONTAL FROZEN FOOD VEGETABLE PACKING MACHINE/ FOOD TRAY FLOW WRAPPING MACHINE

Applicable

It is suitable for packing frozen food with tray, such as dumpling, wonton, steamed stuffed bun, dumpling, etc

Product Detail

Video Information

Specification

Model: ZB602S
Center distance 150mm
Bag size L 120-600mm
  W 200mm
  H 35-80mm
Packing speed 25-150 bags/min
Packing the biggest film width 600mm
Power supply 220V 50HZ
Total power 4kw
Machine weight 1350kg
Outside dimension 4330*1205*1563mm

Main characteristics & Structure features

1 .The operation of the whole machine is completed by the motion controller, with a large LCD screen, and the working state of the machine is clear at a glance.

2.Transmission servo mechanism, sealing and cutting position is accurate, stop position, printing position can be set arbitrarily;Simple mechanical structure, convenient debugging, intuitive;Wide range of packaging, to adapt to a variety of product specifications.

3.The mechanism layout in line with human engineering mechanics can facilitate and quickly clean up, maintain, maintain and overhaul the machine, reduce the labor intensity of the operator and effectively improve the production efficiency

optional accessories
