VFFS LIQUID PACKING MACHINE WITH 5KG SAUCE OR PEPPER WITH LIQUID PACKING MACHINE YL400

Model: YL-400
Filling capacity 500-7500 ml
Packing speed 15-20 bags/min
Finished bag size range L:120-500 mm W:100-250mm
Packaging type back sealing
Power supply 380V 50Hz,1 PH
Compressed air consumption 6kg/cm² 300L/min
Machine noise ≤75db
General power 3Kw
Machine weight 620Kg
Packing film Applicable for transparent complex film


Product Detail

Video Information

Applicable

Food: seasoning soy, egg white, vegetable juice, jam, salad sauce, thick chilisauce, fish and meat stuffing, lotus-nut paste, sweetened bean paste and 0ther stuffing as well as drinks of large bulk. Non-food: oil, detergent, grease, industrial paste,etc.

酱
酱汁

Main characteristics & Structure features

1. Strong machine structure, human-machine interface with multi-languages.

2. Automatic weighing, filling, and sealing machine for common, liquid, common viscosity liquid,

high  viscosity liquid.

3. It adopts imported mechanical and pneumatic units which ensure machine wear well.

4. Adopts squeezing and exhausting packaging method, wide range packing specification.

5. Can be equipped with various kinds of weighing and filling device.

6. The machine design conforms to National GMP standard, and the electric safely protection

system has passed CE norm.
