VFFS FOR SECONDARY PACKAGING OR BIG BAG WITH 5KG NUTS PACKING MACHINE

Applicable

It is suitable for automatic packaging of granular strip, sheet, block, ball shape, powder and other products. Such as snack, chips, popcorn, puffed food,dried fruits, cookies, biscuits, candies, nuts, rice,beans, grains, sugar, salt, pet food, pasta, sunflower seeds, gummy candies, lollipop, Sesame.

Product Detail

Video Information

Specification

Model: ZL350
Bag size Laminated film
Average speed 15-70bags/min
Packing film width 200-730 mm
Bag size L 80-430 mm W 90-350 mm
Machine noise ≤75db
Air consumption 6kg/m²
General power 5.8kw
Main motor power 1.81kw
Machine weight 1050kg
Power supply 220V 50Hz.1Ph
Outside dimensions 2150mm*1500mm*2090mm

Main characteristics & Structure features

1. The whole machine adopts double servo control system, can based on different product and film material to choose different servo film pulling structure. Can equip with vacuum absorb film system;

2. Horizontal sealing servo control system can realize automatic setting and adjustment of horizontal sealing pressure;

3. Various packing format; pillow bag, ironing bag, gusset bag, triangle bag, punching bag, continuous bag;

4. It can be combined with multi-head scale , screw scale, electronic scale, volume cup system and other measuring  equipment, to achieve accurate measuring;

optional accessories

10 HEADS WEIGHER

●  Features
1. One of the most economic&stable multi-head weigher in the world the best cost-effective
2. Stagger Dump avoid bigger items pile up
3. Individual feeder control
4. User friendly touch screen equipped with multiple language
5. Compatible with single packaging machine, rotary bagger, cup/bottle machine, tray sealer etc.
6. 99 preset program for multiple tasks.

1_副本
 Item  Standard 10 multi head weigher
 Generation  2.5G
 Weighing range  15-2000g
 Accuracy  ±0.5-2g
 Max speed  60WPM
 Power supply  220V , 50HZ, 1.5KW
 Hopper volume  1.6L/2.5L
 Monitor  10.4 inches color touch screen
 Dimension (mm)  1436*1086*1258
 1436*1086*1388



001

Z-TYPE CONVEYOR

●  Features

The conveyer is applicable for vertical lifting of grain material in departments such as corn, food, fodder and chemical industry, etc. For the lifting machine,

the hopper is driven by the chains to lift. It’s used for vertical feeding of grain or small block material. It has advantages of large lifting quantity and highness.


●  Specification

Model ZL-3200 HD
Bucket hopper 1.5 L
Capacity(m³h) 2-5 m³h
Bucket material PP Food Gradewe have developed dozens of bucket molds  ourselves
Bucket style Slippy bucket
Framework material Sprocket: Mild steel with chrome coatingAxis: Mild steel with nickel coating
Dimension Machine height 3100*1300 mmStandard export case 1.9*1.3*0.95
Optional parts Frequency converterSensorPan for leakage product
The material and brand of the internal parts of the machine can be specified , and it can be be selected according to the product and service environment of the machine



005

SUPPORTING PLATFORM

●  Features

The supporting platform is solid will not affect the measurement accuracy of the combination weigher.

In addition, the table board is to use the dimple plate, it is more secure, and it can avoid slipping.

●  Specification

The size of the supporting platform is according to the type of the machines.

OUTPUT CONVEYOR

●  Features

The machine can send the packed finished bag to after-package detecting device or packing platform.

●  Specification

Lifting height 0.6m-0.8m
Lifting capacity 1 cmb/hour
Feeding speed 30m\minute
Dimension 2110×340×500mm
Voltage 220V/45W
003
