DUMPLING MAKING MACHINE DUMPLING LACE SKIRT SHAPE [ SOONTRUE ]
It is suitable for automatic making various dumplings and any kinds of stuffing dumplings. By equip some mold and mechanisam. It can produce dumpling lace skirt shape, lace gyoza, wonton making and siomai making as well. This kind of dumplings can be boiled, steam, frying. Its suitable for different request.
|Model||XSJ10A lacy dumpling making machine|
|Machine Material||304 food grade stainless steel|
|Specification||18g (skin:7~8g, inside:10~11g)|
|Forming station||8 stations|
|Servo motor||3 set of inovance brand servo4 set of KESHI brand servo|
|Stepping motor||4 Set (china brand)|
|1phase motor||1 SET (made in china)|
|Production speed||30~60 pcs/min (based on dumpling skin and inside craft)|
|Air consumption||0.4~0.6MP; 100L/min|
|Power supply||220V 50HZ 1PH|
Main characteristics & Structure features
1. Easy operation, The whole machine with 4 operating button, humanization design. Lower requirements for production operators.
2. Easy cleaning. The stuffing system part adopt quick release design. So whole machine cleaning can be finished within 30 minutes.
3.Economic and efficient, this machine adopt patent dumpling skin and forming design. With lower requirements for dumpling skin and stuffing material. With high efficiency on dumpling skin, and final product more efficiency.
DUMPLING MACHINE ADVANTAGES
Skin making part
This area is designed as 3-stage dumpling skin pressing structure. Precise skin thickness makes better dumpling texture. Skin recycling system greatly improves the utilization rate of the dough. The whole area has no sanitary corners, easy to maintain.
The servo motor imitates the manual wrapping, and the wrapping force is adjustable to ensure that the dumpling wrapper is tightly wrapped, beautiful and does not affect the taste of the dumpling.
Dumpling stuffing device
The piston-type servo motor automatically fills the stuffing, the filling amount is accurate, and the inner cylinder is equipped with a cutting knife in one step, which greatly solves the problem of stuffing on the side of the dumplings.
Skin cutting Device
Automatic skin cutting device with protective cover, accurate positioning and neatly cutting, with high passing rate. Realizing standardized dumpling skin with nice appearance.
Q1: Does the dumpling maker machine have the function of flour mixing?
Answer: No, it doesn’t. The dumpling wrapper machine can only make dumpling skins from dough. You need an additional dough mixer to make the dough first, then put it in dough bucket of the machine.
Q2:Does the dumpling wrapping machine have leftover dumpling skins recycle function?
Answer: Yes, it does. The leftover dumpling skins will be recycled through the entrance in the middle of the turntable and sent back to the dough bucket for use. This design can save materials and effectively reduce production costs.
Q3:Can a machine produce dumplings of different shapes by changing molds?
Answer: No, it can’t. Since the forming process of different dumplings is different, each dumpling machine can only make dumplings of a specific shape. We highly recommend one machine for one shape in order to improve daily production efficiency.
Q4:Is the dumpling making machine easy to operate?
Answer: Yes, it is. The thickness of the professional dumpling machine is adjusted by three rollers, which is intuitive and easy to use. In addition, the machine uses a combination of servo motors and stepping motors, and most of the adjustments are realized through the HMI, which is easy to operate.
Q5:Is the daily maintenance of the dumpling wrapping machine convenient?
Answer: Yes, it is. The dough pressing area on the left can be cleaned with compressed air. In the dumpling forming area on the right, can be washed with water. And the stuffing filling assembly is with tool-free quick disassembly design.
