WATER PACKING MACHINE | LIQUID PACKING MACHINE SOONTRUE

Applicable

Suitable for pickle, plum vegetable, mushroom, dried turnip, ginger, pickled vegetable, jellyfish, fish sauce, etc.



1

Product Detail

Video Information

Specification

Model: ZL230
Bag size: L: 80mm-300mm
  W: 80mm-200mm
Suitable film width: 130mm~320mm
Packing speed: 15-70 bags/min
Packing film: Laminated film
Power supply: 220V 50Hz, 1 PH
Compress air consuming: 6kg/ c㎡, 250L/min
Machine noise: ≤75dB
General power: 4.0kw
Weight: 650kg
Outer dimension: 1770 mm x1105 mm x 1500 mm



Main characteristics & Structure features

1 .The whole machine adopts uniaxial or biaxial servo control system, which can choose two kinds of servo single film pulling and double film pulling structure according to the different characteristics of packing material and can choose vacuum adsorption pull film system;

2. Horizontal sealing system can be pneumatic drive system or servo drive system, to meet the diverse needs of different users;

3. Various packing format:pillow bag, side ironing bag, gusset bag, triangle bag, punching bag, continuous bag type;

4. It can be combined with the multi-head weigher, auger scale, volume cup system and other measuring equipment, accurate and measurement;

5. The design of the whole machine conforms to GMP standard and has passed CE certification

optional accessories

PISTON PUMP

1641281783(1)

Machine Specifications



The liquid filler can fill low viscosity material (material like water, oil etc) to medium viscosity material (like shampoo or liquid detergent etc.), connect the material inlet pipe to your raw material tank, it can absorb the material from that tank directly

• Durable All Stainless Steel 304 Construction to meet the current GMP Standard



Specifications & Accessories Included

• Adopting advanced pneumatic parts (Germany FESTO or Taiwan AIRTAC)

• Cylinder and Filling Nozzle made up of 316L stainless steel and polyethylene with Teflon, it accord with GMP standard

• Filling range and filling speed can be adjusted by manual

• Filling set adopts preventing leaking nozzle

• Changeable nozzle tips

• Filling precision: > 99.5%



Spare Parts and Accessories are Included

• New type acid resistance sealing ring (01 set)

• Material pipe Included

• Tools Included



Parameter

Model

Filling Range

Ideal Filling Range

Filling Error

Capacity (per min)

Other Parameters

VLF-100

10~100ml 0.35~3.53oz

20~100ml 0.71~3.53oz

Within ±0.5%

40-80

Power Supply: AC110/220,50Hz

Power: 25W

Air Supply: 0.4~0.5MPa
58~72.6psi

Air Consumption:
0.28 - 0.70m³/min

VLF-250

25~250ml 0.88~8.82oz

50~250ml 1.76~8.82oz

Within ±0.5%

30-45

VLF-500

50~500ml 1.76~17.64oz

100~500ml 3.53~17.64oz

Within ±0.5%

25-35

VLF-1000

100~1000ml 3.53~35.27oz

200~1000ml 7.05~35.27oz

Within ±0.5%

15-24

VLF-2000

200~2000ml  7.05~70.55oz

400~2000ml 14.11~70.55oz

Within ±0.5%

10-18

VLF-5000

500~5000ml   17.64~176.37oz

1000~5000ml 35.27~176.37oz

Within ±0.5%

5-12
