VFFS MACHINE | FOOD PACKAGING MACHINE

Applicable

It is suitable for automatic packaging of granular strip, sheet, block, ball shape, powder and other products. Such as snack, chips, popcorn, puffed food,dried fruits, cookies, biscuits, candies, nuts, rice,beans, grains, sugar, salt, pet food, pasta, sunflower seeds, gummy candies, lollipop, Sesame.

Product Detail

Video Information

Specification

Model:	ZL180PX
Packing material	Laminated flm
Bag size:	L: 50mm-170mm W: 50mm-150mm
Packing speed:	20-100 bags/min
Machine noise:	≤75dB
General power:	4kw
Machine Weight:	350kg
Air consumption	6kg/ c㎡
Power supply:	220V 50Hz, 1 PH
Outer dimension:	1350* 1000mm*2350mm

Main characteristics & Structure features

1. The whole machine use 3 servo control system, running stability, high accuracy, fast speed, lower noisy.

2. It adopt touch screen operate, more easy, more intelligent.

3.Various packing type: pillow bag, punch hole bag, connect bags etc.

4. This machine can equip with multi-head weigher , electrical weigher, volume cup etc.

THE DETAILS ARE POLISHED FOR YOU

Intelligent interface
Touch screen intelligent PLC control system, own fault alarm system, easy to operate

Auger scale device
Accurate measurement, high weighing accuracy, fast speed, meet the requirements of a variety of measurement packaging, convenient and easy
Adjust recipe.

Film puling system
The film pulling is stable, accurate, high positioning accuracy, equipped with coding adjustment, eye mark tracking adjustment, whether with film or not

Horizontal sealing system
Horizontal sealing servo system control, specially designed, fast packaging speed.Sealing temperature is controlled by constant temperature and the cut is neat and beautiful
