VINEGAR 3 SIDE FILLING MACHINE AND OIL 4 SIDE SEALING MACHINE

Applicable

It is suitable for seasoning soy, egg white, vegetable juice, jam, salad sauce, thick chilisauce, fish and meat stuffing, lotus-nut paste, sweetened bean paste and Other stuffing as well as drinks of large bulk. Non-food: oil, detergent, grease, industrial paste,etc.

Product Detail

Video Information

Specification

Model: YL-150ZB
Fillers Liquid, the viscous body
Packing type three side, four side seal
Packing speed 40-200 bags/min
Filling  capacity 1-30ml
Bag length 40-120mm
Bag width 40-100mm
Power supply Single phase 220V 50HZ
Air consumption 0.6Mpa
Machine noise ≤75db
Packing material Suitable for transparent complex film
Total power 6.5kw
Machine weight 650kg
Machine size 1200mm×1150×1900mm

Main characteristics & Structure features

1. The machine has the characteristics of good sealing, clear sealing, fast, compact structure, smooth operation and low noise.

2. Solid main body, man-machine interface corresponding to various characters

3. It can satisfy all kinds of pure liquid, general viscosity, high viscosity material automatic metering bag filling packaging.

4.The liquid filler can fill low viscosity material (material like water, oil etc) to medium viscosity material (like shampoo or liquid detergent etc.), connect the material inlet pipe to your raw material tank, it can absorb the material from that tank directly

5. The machine has the characteristics of good sealing, clear sealing, fast, compact structure, smooth operation and low noise.

6. Solid main body, man-machine interface corresponding to various characters

7. It can satisfy all kinds of pure liquid, general viscosity, high viscosity material automatic metering bag filling packaging.

• Durable All Stainless Steel 304 Construction to meet the current GMP Standard

Specifications & Accessories Included
• Adopting advanced pneumatic parts (Germany FESTO or Taiwan AIRTAC)
• Cylinder and Filling Nozzle made up of 316L stainless steel and polyethylene with Teflon, it accord with GMP standard
• Filling range and filling speed can be adjusted by manual
• Filling set adopts preventing leaking nozzle
• Changeable nozzle tips
• Filling precision: > 99.5%

optional accessories

1532
40

sauce

OUTPUT CONVEYOR

●  Features

The machine can send the packed finished bag to after-package detecting device or packing platform.

●  Specification

Lifting height 0.6m-0.8m
Lifting capacity 1 cmb/hour
Feeding speed 30mminute
Dimension 2110×340×500mm
Voltage 220V/45W



003
